GDS® Uni-Conn™ Powered Snap-In Dock with USB-C Connector
One Dock to Connect Them All™
$87.49
Overview
The GDS® Uni-Conn™ Powered Snap-In Dock with USB-C Connector (RAM-GDS-DOCK-U3CPU) is a versatile snap-in docking solution for devices enclosed in an IntelliSkin® Thin-Case™ with rear pogo pads. Power is provided to the pogo pins integrated into the GDS® Uni-Conn™ adapter via the USB-C connector. This dock features a 2-hole AMPS pattern, allowing it to be integrated into the RAM® ball and socket mounting system with a RAM® Diamond or Round Ball Base. The snap-in attachment method makes this dock ideal for rugged environments, including vehicles. The GDS® Uni-conn™ dock is backed by a 3-year warranty. Warranty is void if lever stop is not installed. One Dock to Connect Them All™ Always Protected. Always Connected.®
Features
- Snap-in dock featuring GDS® Technology™ uses an integrated pogo pin connector to provide high-speed charging
- Designed for devices enclosed in the IntelliSkin® Thin-Case™ with Rear Pogo Pads
- USB Type-C female connector enables high-speed charging capabilities
- Backed by a 3-year warranty
hardware included:
(1) Lever Stop
(2) #8-32 x 1.125" Machine Screws
(2) #8-32 Nylock Nuts
hole pattern:
2-Hole AMPS: 1.912"
materials:
High strength composite
packaging type:
Poly Bag
output voltage:
USB-C Tablets: 5V - 20V @ 3A Max
mUSB Tablets: 9V @ 1.67A Max
power output:
60W Max
input connector:
USB Type-C (Female)
input cable length:
800mm
Warranty:
3 year warranty
Weight:
0.33 lb
Additional Information:
The Lever Stop included with this dock is required in order to function properly. Warranty on dock is void if dock is used without Lever Stop. GDS® Uni-Conn™ docks are not recommended for high vibration applications such as forklifts.
Return Policy:
All products purchased from RAM® can be returned within 30 days with no restocking fee (return shipping not provided). See full return policy here.
Questions & Answers
Have a Question?
-
What is the RAM® ball component size that this item is designed for?
This is compatible with our diamond plate withball RAM® Diamond BallBase. You can see the different size balls this plate comes with in theoptions drop down under the pricing.
-
How long is the cord
The cord is 800 mm, or 31.5 inches.
