RAM® Tab-Tite™ with RAM® Pod™ I Vehicle Mount for Small Tablets
Part #: RAM-B-316-1-TAB-SM UPC: 793442942754 Patented

Product Information
Overview	The RAM-B-316-1-SM consists of the RAM POD I universal No-Drill™ vehicle base, 18” rigid aluminum rod, socket system, Tab-Tite™ cradle and 3 sets of cup ends to accommodate for tablets of various sizes. The base of the mount connects to your seat rail without any drilling necessary. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The spring loaded, quick release Tab-Tite™ cradle makes it easy to load and unload your tablet, along with keeping it secure while on the go. Cup ends are designed to optimize the functionality of your tablet, allowing access to audio jacks, usb, power, and other ports, your iPad can be used just as it was intended.

Product Information

Overview

The RAM-B-316-1-SM consists of the RAM POD I universal No-Drill™ vehicle base, 18” rigid aluminum rod, socket system, Tab-Tite™ cradle and 3 sets of cup ends to accommodate for tablets of various sizes. The base of the mount connects to your seat rail without any drilling necessary. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The spring loaded, quick release Tab-Tite™ cradle makes it easy to load and unload your tablet, along with keeping it secure while on the go. Cup ends are designed to optimize the functionality of your tablet, allowing access to audio jacks, usb, power, and other ports, your iPad can be used just as it was intended.

Specifications
hardware included	Assembly Hardware
holder dimensions	Height Range: 7" - 10" Width Range: 4" - 5.31" Depth Range: .44" - 1.06"
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	Marine-grade aluminum High strength composite
packaging type	Box
Weight	3.45 lb

RAM® Tab-Tite™ with RAM® Pod™ I Vehicle Mount for Small Tablets

Questions about our products? Email us for support.

Patented

RAM® Tab-Tite™ with RAM® Pod™ I Vehicle Mount for Small Tablets

Part#: RAM-B-316-1-TAB-SM

UPC: 793442942754

B Size

Size Guide

Ball Size
Arm Sizes

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured by a multitude of interchangeable components to fit your specific needs.

A Size

Holds .5 lbs.

Trail Cameras

B Size

Holds 2 lbs.

Phones, Action Cameras, Light Duty Tablets

C Size

Holds 4 lbs.

Fishfinders, Heavy Duty Tablets

D Size

Holds 6 lbs.

Heavy Monitors

E Size

Holds 15 lbs.

Heavy Monitors

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.

Size	A Size	B Size	C Size	D Size	E Size
Short Arm	Overall Length N/A	Overall Length 2.42"	Overall Length 3.56"	Overall Length 5.69"	Overall Length 5.69"
Short Arm	Socket-to-Socket Length N/A	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 2.5"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 4.66"
Medium Arm	Overall Length 2.42"	Overall Length 3.73"	Overall Length 5.69"	Overall Length 8.44"	Overall Length 12.63"
Medium Arm	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 3"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 6.88"	Socket-to-Socket Length 9.88"
Long Arm	Overall Length 6"	Overall Length 6"	Overall Length 9.13"	Overall Length 12.98"	Overall Length N/A
Long Arm	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 8"	Socket-to-Socket Length 11.41"	Socket-to-Socket Length N/A

$125.99
