RAM^® Double Ball Mount for Lowrance Eagle 4 & 5, Hook² & Reveal 5
Part #: RAM-101-LO12 UPC: 793442956072 Patented

Product Information
Overview	Designed for heavy duty fresh water use, this C size (1.5”) aluminum drill-down kit for the Lowrance Elite 4 & 5 and Hook² allows users to swap out the factory mounting solution with a RAM^® Mounts solution. Simply attach the included adapter to the Lowrance Eagle 4 & 5 and Hook² and you're ready to connect the double socket arm and round base featuring the AMPS hole pattern. Made of high strength composite and powder coated marine grade aluminum, this kit is designed to keep your Hook² secure and stable in rugged environments on your boat, kayak or inflatable.

Product Information

Overview

Designed for heavy duty fresh water use, this C size (1.5”) aluminum drill-down kit for the Lowrance Elite 4 & 5 and Hook² allows users to swap out the factory mounting solution with a RAM^® Mounts solution. Simply attach the included adapter to the Lowrance Eagle 4 & 5 and Hook² and you're ready to connect the double socket arm and round base featuring the AMPS hole pattern. Made of high strength composite and powder coated marine grade aluminum, this kit is designed to keep your Hook² secure and stable in rugged environments on your boat, kayak or inflatable.

Specifications
hardware included	Assembly Hardware
product dimensions	Overall Height: 7.35"
socket to socket length	4.66"
hole pattern	4-Hole AMPS: 1.181" x 1.496" 3-Hole 120-Degree: 1.812" Diameter
plate size	2.5" Diameter
ball size	C Size (1.5")
weight capacity	Standard Use: 4 lbs Heavy-Duty Use: 3 lbs
materials	Marine-grade aluminum High strength composite
packaging type	Retail Bag
Weight	1.2 lb
