RAM^® Flex-Rod^™ 18" Single Socket Arm with Drill-Down Base Accessories
Part #: RAP-B-200-1-386-18U UPC: 793442941429 Patented

Product Information
Overview	The RAP-B-200-1-386-18U consists of a interchangeable post/base pinlock system, 18" rigid aluminum rod and single socket arm for 1" ball bases/adapters. The interchangeable post/base system includes a diamond, round and square base, all containing the universal AMPs hole pattern. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The single socket is compatible with all 1" ball bases and adapters.

Product Information

Overview

The RAP-B-200-1-386-18U consists of a interchangeable post/base pinlock system, 18" rigid aluminum rod and single socket arm for 1" ball bases/adapters. The interchangeable post/base system includes a diamond, round and square base, all containing the universal AMPs hole pattern. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The single socket is compatible with all 1" ball bases and adapters.

Specifications
hardware included	Assembly Hardware
hole pattern	2-Hole AMPS: 1.912" 4-Hole AMPS: 1.181" x 1.496"
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	High strength composite
packaging type	Poly Bag
Weight	0.9 lb

RAM<sup>®</sup> Flex-Rod<sup>™</sup> 18" Single Socket Arm with Drill-Down Base Accessories

Questions about our products? Email us for support.

Patented

RAM^® Flex-Rod^™ 18" Single Socket Arm with Drill-Down Base Accessories

Part#: RAP-B-200-1-386-18U

UPC: 793442941429

B Size

Size Guide

Ball Size
Arm Sizes

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured by a multitude of interchangeable components to fit your specific needs.

A Size

Holds .5 lbs.

Trail Cameras

B Size

Holds 2 lbs.

Phones, Action Cameras, Light Duty Tablets

C Size

Holds 4 lbs.

Fishfinders, Heavy Duty Tablets

D Size

Holds 6 lbs.

Heavy Monitors

E Size

Holds 15 lbs.

Heavy Monitors

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.

Size	A Size	B Size	C Size	D Size	E Size
Short Arm	Overall Length N/A	Overall Length 2.42"	Overall Length 3.56"	Overall Length 5.69"	Overall Length 5.69"
Short Arm	Socket-to-Socket Length N/A	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 2.5"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 4.66"
Medium Arm	Overall Length 2.42"	Overall Length 3.73"	Overall Length 5.69"	Overall Length 8.44"	Overall Length 12.63"
Medium Arm	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 3"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 6.88"	Socket-to-Socket Length 9.88"
Long Arm	Overall Length 6"	Overall Length 6"	Overall Length 9.13"	Overall Length 12.98"	Overall Length N/A
Long Arm	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 8"	Socket-to-Socket Length 11.41"	Socket-to-Socket Length N/A
