Patented & Pats. Pend.
GDS® Uni-Conn™ Locking Tilt & Swivel Dock with PoE + Data
One Dock to Connect Them All™
Part#: RAM-GDS-DOCKLR-D14-U1E-2A
UPC: 793442023880
$515.49

Overview

The GDS® Uni-Conn™ Locking Tilt & Swivel Dock with PoE + Data (RAM-GDS-DOCKLR-D14-U1E-2A) is a free-standing, powered dock for devices enclosed in an IntelliSkin® Next Gen, IntelliSkin® Hard Case, or standard IntelliSkin® Thin-Case™ with a GDS® Uni-Conn™ adapter. This solution can swivel 180 degrees and allows devices to tilt 180 degrees, which is ideal for customer-centric industries like retail, hospitality, food service, and more. Power over Ethernet (PoE) is provided to the pogo pins integrated into the GDS® Uni-Conn™ dock via RJ45 connection while the two USB-A ports on the back support up to two input devices like keyboard, mouse, scanner gun, and more. This dock features a weighted base and rubber pads that offer theft deterrence and prevent it from sliding around on surfaces. Keep your device safe in high-traffic environments with the key lock, integrated to provide additional theft deterrence. One Dock to Connect Them All™ Always Protected. Always Connected.®

Features

  • Key-locking, free-standing, powered Kiosk dock for devices enclosed in an IntelliSkin® with D-shaped bottom connection and GDS® Uni-Conn™ Adapter
  • GDS® Uni-Conn™ dock pogo pins provide Power over Ethernet (PoE) via RJ45 connector
  • Dock swivels 180 degrees and enables connected devices to tilt 180 degrees
  • Weighted base with rubber pads prevents kiosk from moving
  • Backed by a 3-year warranty

hardware included:

(1) RAM® PoE to PD Charging Module

product dimensions:

Height from Base to Tilt Bolt: 5.52"
Base Width: 5.13"
Base Depth: 6.63"

materials:

High Strength Composite

packaging type:

Box

output voltage:

USB PD 3.0:
5V @ 3A
9V @ 2.2A
12V @ 1.7A

power output:

24W Max

input connector:

JST Male Connector

input cable length:

1.5 Meters

transfer speed:

10/100Mbps

ports:

(2) USB-A

Warranty:

3 year warranty

Weight:

6.72 lb

Print

Documents

GDS® Uni-Conn™ Powered Tilt & Swivel Dock Buyer Guide
