RAM^® Track Ball^™ Double Ball Mount for Humminbird Helix 5
Part #: RAP-B-202-153-354-TRA1U UPC: 793442955099

Product Information
Overview	The RAP-B-202-153-354-TRA1U consists of a Track Ball^™ base, composite double socket arm and 1.5" x 3" rectangular plate. The rectangular plate contains four holes that will line up with the Humminbird Helix 5. The Track Ball^™ will connect to virtually any track system including the RAM Tough-Track^™

Specifications
hardware included	(1) Friction Washer (1) 1/4"-20 x 7/8" T-Bolt
t bolt dimensions	.48" x .95"
socket to socket length	3"
hole pattern	1" x 2.5"
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	High strength composite
packaging type	Poly Bag
Weight	0.41 lb
