RAM^® Track Ball^® Composite Fishfinder Mount for Humminbird Devices
Part #: RAP-B-107B-354-TRA1U UPC: 793442955075

Product Information
Overview	The RAP-B-107B-354-TRA1U consists of a Track Ball^™ base, composite double socket arm and connecting Humminbird/Apelco marine adapter base. The mount is designed with a RAM 1" diameter rubber ball and socket system that has adjustment points at both ends of the double socket arm - allowing for high adjustability to achieve perfect viewing angles. This kit is compatible with virtually any track system including the RAM Tough-Track^™.

Product Information

Overview

The RAP-B-107B-354-TRA1U consists of a Track Ball^™ base, composite double socket arm and connecting Humminbird/Apelco marine adapter base. The mount is designed with a RAM 1" diameter rubber ball and socket system that has adjustment points at both ends of the double socket arm - allowing for high adjustability to achieve perfect viewing angles. This kit is compatible with virtually any track system including the RAM Tough-Track^™.

Specifications
hardware included	(1) Friction Washer (1) 1/4"-20 x 7/8" T-Bolt
socket to socket length	3"
hole pattern	See Drawing
plate size	4.25" x 3.81"
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	Marine-grade aluminum High strength composite
packaging type	Poly Bag
Weight	0.48 lb

RAM<sup>®</sup> Track Ball<sup>®</sup> Composite Fishfinder Mount for Humminbird Devices

Questions about our products? Email us for support.

RAM^® Track Ball^® Composite Fishfinder Mount for Humminbird Devices

Part#: RAP-B-107B-354-TRA1U

UPC: 793442955075

B Size

Medium Arm

Size Guide

Ball Size
Arm Sizes

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured by a multitude of interchangeable components to fit your specific needs.

A Size

Holds .5 lbs.

Trail Cameras

B Size

Holds 2 lbs.

Phones, Action Cameras, Light Duty Tablets

C Size

Holds 4 lbs.

Fishfinders, Heavy Duty Tablets

D Size

Holds 6 lbs.

Heavy Monitors

E Size

Holds 15 lbs.

Heavy Monitors

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.

Size	A Size	B Size	C Size	D Size	E Size
Short Arm	Overall Length N/A	Overall Length 2.42"	Overall Length 3.56"	Overall Length 5.69"	Overall Length 5.69"
Short Arm	Socket-to-Socket Length N/A	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 2.5"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 4.66"
Medium Arm	Overall Length 2.42"	Overall Length 3.73"	Overall Length 5.69"	Overall Length 8.44"	Overall Length 12.63"
Medium Arm	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 3"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 6.88"	Socket-to-Socket Length 9.88"
Long Arm	Overall Length 6"	Overall Length 6"	Overall Length 9.13"	Overall Length 12.98"	Overall Length N/A
Long Arm	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 8"	Socket-to-Socket Length 11.41"	Socket-to-Socket Length N/A
