RAM® Magnetic Microphone Adapter with Ball
Part #: RAM-B-508U UPC: 793442037122 Features Strong embedded magnet securely holds compatible handheld microphones Integrated 1" RAM® B-size ball connects to RAM® Mounts ecosystem for adjustable positioning Made of powder-coated, marine-grade aluminum and high-strength composite for durability and reliability in the most demanding environments Backed by a lifetime warranty

Product Information

Overview

The RAM® Magnetic Microphone Adapter with Ball (RAM-B-508U) is a mounting accessory that allows for easy, one-handed operation of Push-to-Talk microphones, with an included B-size ball for easy integration. Featuring a strong embedded magnet, this compact adapter securely holds compatible microphones while allowing for quick removal and docking. Constructed from high-strength composite materials, it's built for demanding fleet, public safety, commercial transportation, and field service environments. The integrated 1" B-size ball is compatible with RAM® double socket arms, making it easy to position your microphone exactly where it's most convenient. This adapter helps eliminate clutter by keeping microphones securely stowed yet instantly accessible when needed. To check if your microphone is compatible, please see the "Compatibility" tab listed above.

Specifications
hardware included	Assembly Hardware
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	Marine-grade aluminum High strength composite
packaging type	Poly Bag

RAM® Magnetic Microphone Adapter with Ball

Name: RAM® Magnetic Microphone Adapter with Ball
Brand: RAM Mounts
SKU: RAM-B-508U
Availability: OutOfStock

Part#: RAM-B-508U

UPC: 793442037122

Kit Components

RAP-508U:RAP-508U_1:RAM Magnetic Microphone Adapter

RAM® Magnetic Microphone Adapter RAP-508U

RAM-B-238U:RAM-B-238U_1:RAM Diamond Ball Base - B Size

RAM® Diamond Ball Base - B Size RAM-B-238U $9.99

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured by a multitude of interchangeable components to fit your specific needs.

A Size

Holds .5 lbs.

Trail Cameras

B Size

Holds 2 lbs.

Phones, Action Cameras, Light Duty Tablets

C Size

Holds 4 lbs.

Fish Finders, Heavy Duty Tablets

D Size

Holds 6 lbs.

Heavy Monitors

E Size

Holds 15 lbs.

Heavy Monitors

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.

Size	A Size	B Size	C Size	D Size	E Size
Short Arm	Overall Length N/A	Overall Length 2.42"	Overall Length 3.56"	Overall Length 5.69"	Overall Length 5.69"
Short Arm	Socket-to-Socket Length N/A	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 2.5"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 4.66"
Medium Arm	Overall Length 2.42"	Overall Length 3.73"	Overall Length 5.69"	Overall Length 8.44"	Overall Length 12.63"
Medium Arm	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 3"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 6.88"	Socket-to-Socket Length 9.88"
Long Arm	Overall Length 3.56"	Overall Length 6"	Overall Length 9.13"	Overall Length 12.98"	Overall Length N/A
Long Arm	Socket-to-Socket Length 3.12"	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 8"	Socket-to-Socket Length 11.41"	Socket-to-Socket Length N/A

Overview

Features

Strong embedded magnet securely holds compatible handheld microphones
Integrated 1" RAM® B-size ball connects to RAM® Mounts ecosystem for adjustable positioning
Made of powder-coated, marine-grade aluminum and high-strength composite for durability and reliability in the most demanding environments
Backed by a lifetime warranty
