RAM® Pod™ I Locking Vehicle Mount with 30" Rod and Round Plate
Part #: RAM-B-316-1L-30-202U UPC: 793442945120 Patented

Product Information
Overview	The RAM-B-316-1L-30-202U consists of the RAM POD I universal No-Drill™ vehicle base, 30” rigid aluminum rod, single 1" ball socket arm, locking knob and round base adapter. The base of the mount connects to your seat rail without any drilling necessary. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The RAM locking knob, includes a brass 1/4"-20 thread, allowing you to disengage the screwing of the knob. Once you have set your mount in the location you need, you can lock it in place and feel safe that your mounted device will stay right where you left it. The 2.5" diameter round base adapter contains the universal AMPS hole pattern.

Product Information

Overview

The RAM-B-316-1L-30-202U consists of the RAM POD I universal No-Drill™ vehicle base, 30” rigid aluminum rod, single 1" ball socket arm, locking knob and round base adapter. The base of the mount connects to your seat rail without any drilling necessary. The 18" rigid aluminum rod can be bent to position your device to its optimum viewing location. The RAM locking knob, includes a brass 1/4"-20 thread, allowing you to disengage the screwing of the knob. Once you have set your mount in the location you need, you can lock it in place and feel safe that your mounted device will stay right where you left it. The 2.5" diameter round base adapter contains the universal AMPS hole pattern.

Specifications
hardware included	Assembly Hardware (2) Keys
hole pattern	4-Hole AMPS: 1.181" x 1.496" 3-Hole 120-Degree: 1.812" Diameter
ball size	B Size (1")
weight capacity	Standard Use: 2 lbs Heavy-Duty Use: 1 lb
materials	Marine-grade aluminum High strength composite
packaging type	Poly Bag
Weight	2.2 lb

RAM® Pod™ I Locking Vehicle Mount with 30" Rod and Round Plate

Questions about our products? Email us for support.

Patented

RAM® Pod™ I Locking Vehicle Mount with 30" Rod and Round Plate

Part#: RAM-B-316-1L-30-202U

UPC: 793442945120

B Size

Size Guide

Ball Size
Arm Sizes

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured by a multitude of interchangeable components to fit your specific needs.

A Size

Holds .5 lbs.

Trail Cameras

B Size

Holds 2 lbs.

Phones, Action Cameras, Light Duty Tablets

C Size

Holds 4 lbs.

Fishfinders, Heavy Duty Tablets

D Size

Holds 6 lbs.

Heavy Monitors

E Size

Holds 15 lbs.

Heavy Monitors

The unique double ball and socket design allows you to adjust your mount to the perfect viewing or operating angle, all with the turn of a single knob. This modular design can be configured with a variety of interchangeable components to fit your specific mounting needs.

Size	A Size	B Size	C Size	D Size	E Size
Short Arm	Overall Length N/A	Overall Length 2.42"	Overall Length 3.56"	Overall Length 5.69"	Overall Length 5.69"
Short Arm	Socket-to-Socket Length N/A	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 2.5"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 4.66"
Medium Arm	Overall Length 2.42"	Overall Length 3.73"	Overall Length 5.69"	Overall Length 8.44"	Overall Length 12.63"
Medium Arm	Socket-to-Socket Length 1.75"	Socket-to-Socket Length 3"	Socket-to-Socket Length 4.66"	Socket-to-Socket Length 6.88"	Socket-to-Socket Length 9.88"
Long Arm	Overall Length 6"	Overall Length 6"	Overall Length 9.13"	Overall Length 12.98"	Overall Length N/A
Long Arm	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 5.31"	Socket-to-Socket Length 8"	Socket-to-Socket Length 11.41"	Socket-to-Socket Length N/A
